Pangea Mini R2 by Bowl Keyboard
Pangea Mini is the successor to the Pangea Full Size. The mini has a similar top frame design that gives the keyboard a unique top-down look. The top frame also determines the layout, allowing users to easily switch the layout or aesthetic of their keyboard by simply changing out the top frame!
CASE SPECIFICATIONS
- Materials: 6063 Aluminium, Stainless Steel
- Layout: WKL
- Typing Angle: 8.5 Degrees
- Front Height: 17.5mm
- EKH: 22.7mm
- Weight: 1400-1600g
- Mounting: Gasket
PCB SPECIFICATIONS
- Material: Black FR4
- Thickness: 1.6mm
- Connectivity: JST to Unified Daughterboard
- Customizability: VIA
- Type: Solderable and Hotswap
Case Content
- 1x Top Case
- 1x Bottom Case
- 1x Through Weight
- 1x Top Frame
- 1x Plate of choice
- 1x Solderable or Hotswap PCB
- 1x S2 Unified Daughterboard + JST to JST Cable
- 1x Carrying Case
- 16x Gaskets
- 4x Custom Molded Feet
- All Screws/Parts/Etc for assembly
Disclaimers:
Please note that the images are example images and are for illustration purposes only. The final colours may differ slightly depending on your lightning and environment.
Note that the Patina finishes are random and that each unit is unique and will not match the product image. The product image is an example of colors and patterns that are expected with each colorway. Returns or exchanges are not accepted due to dissatisfaction with the finish.
